NCF660 Series
Active
660 W PSU with CF Level Isolation and Leakage Current
Advanced Energy’s SL Power NCF660 CF rated medically approved open-frame AC-DC power supplies are available with a nominal main output of 12 V, 15 V, 24 V or 48 V. NCF660 series power supplies provide up to 660 W of output power with air flow. All models have output overvoltage, short circuit and overload protection and a 7 x 4 x 1.6 inch form factor.
특징
• CF Rated leakage current <10μA
• 5 kV defibrillator withstand
• Up to 660 W with air flow, 440 W convection
• Meets Class B emissions levels
• 4”W x 7”L x 1.6”H size
• Universal input 85 to 264 VAC, Class I
• Includes 5 V standby output
• IEC/UL/cUL/EN60601-1, Edition3.2
• 5 kV defibrillator withstand
• Up to 660 W with air flow, 440 W convection
• Meets Class B emissions levels
• 4”W x 7”L x 1.6”H size
• Universal input 85 to 264 VAC, Class I
• Includes 5 V standby output
• IEC/UL/cUL/EN60601-1, Edition3.2
혜택
• Long life: 7+ years electrolycti capacitor life
• Ease of integration: Meets Class B emissions and 4th Edition EMC requirements
• 3 years warranty
• RoHS, REACH compliant
• Ease of integration: Meets Class B emissions and 4th Edition EMC requirements
• 3 years warranty
• RoHS, REACH compliant
사양
| 출력 전력(W): | 660 |
|---|---|
| 길이(인치): | 7 |
| 너비(인치): | 4 |
| 높이(인치): | 1.6 |
| 마운팅 유형: | U channel |
| 최소 출력 전류(A): | 9.1 |
| 최대 출력 전류(A): | 46.2 |
| 출력 전압 범위(V): | 12V to 48V |
Featured Resources
Product Information Documents
Safety & Compliance Certificates
Engineering Resources
기술 동영상
NCF660 Series of CF Rated Medical Power Supplies
3월 10, 2025
Advanced Energy’s SL Power NCF660 CF rated medically approved AC-DC power supplies are available with a nominal main output of 12 V, 15 V, 24 V or 48 V. NCF660 series power supplies provide up to 660 W of output power with air flow. All models have output overvoltage, short circuit and overload protection and a 7 x 4 x 1.6 inch form factor.
